HT32F54253 64LQFP
US$1.66
Out of stock
Product ID
HT32F54253-64LQFP
DESCRIPTION
The HT32F54253 is a 32-Bit Arm® Cortex®-M0+ 5V Touch MCU that provides 28 touch keys. It has an operating frequency of up to 60MHz and includes an LED controller with an automatic scanning function. It is suitable for electrical products, such as air fryers, rice cookers, smart door locks, washing machine panels, etc.
NOTE
The product image is for showing the product appearance, the pin count shown may not match the product pin count.
Buy 10 for
US$1.41
each and save 15 %
Buy 100 for
US$1.25
each and save 25 %
Buy 500 for
US$1.08
each and save 35 %
Quantity Discounts
Looking for our Official Distributor in India? SPIN MODULES -INR payment available!
Follow Us for More Updates!
FEATURES
32-bit Arm® Cortex®-M0+ processor core
Up to 60 MHz operating frequency
Up to 128 KB on-chip Flash memory for instruction/data and options storage
Single VDD power supply: 2.5 V to 5.5 V
Integrated 1.5 V LDO regulator for MCU core, peripherals and memories power supply
Two power domains: VDD and VCORE
Supports 8-segment digital displays up to a maximum of 12
Four key oscillator frequencies: 1 MHz / 3 MHz / 7 MHz / 11 MHz
DEVELOPMENT TOOL
Integrated Serial Wire Debug Port (SW-DP)
Support ISP (In-System Programming), IAP (In-Application Programming), ICP (In-Circuit Programming)
Debug Adapter : e-Link32 Pro
Development Environment : Keil uVision, IAR EWARM
RESOURCES
MCU : Holtek HT32F54253 , 32-Bit Arm® Cortex®-M0+ 5V Touch MCU, including datasheet, package dimension, etc.
More Information
HS Code (reference)
8542.31.0000
