BC45B4523 NFC Reader Controller Development Board BCE-45B4523-001

US$ 36.00
In stock
Quantity
7
Product ID
BCE-45B4523-001
DESCRIPTION

NFC (Near-field communication) is a communication protocol that allows two devices to communicate with each other within a short distance. In our daily lives, NFC is used in everything from mobile payments to access control cards and transportation cards.

The BCE-45B4523-001 is an NFC reader IC development board. It is compatible with the ISO14443A, ISO14443B, and ISO15693 protocols. Holtek also provides the Crypto_M encryption and decryption function, which is compatible with Mifare Tag.
- ISO14443A and ISO14443B are suitable for secure data transmission in a short distance, such as mobile payments and access cards.
- ISO15693 is suitable for secure data transmission long distances and is commonly applied in warehouse management.

The BCE-45B4523-001 is composed of three ICs, main control MCU HT32F52241, USB to UART Bridge IC HT42B534-2, and 13.56MHz NFC Reader IC BC45B4523. Holtek provides software, NFCReader_TK, for the development board and NFC tags to make development faster and easier.


Product information

Dimension: 137 x 64 x 12 mm
Net weight: PCB 32.5g / Tags 30g
Product includes:
1. BC45B4523 development board BCE-45B4523-001 x 1
2. NFC tags x 5
- ISO14443A Type 2 x 1
- ISO14443B Type 3 x 1
- ISO15693 Type5 x 1
- Mifare Classes 1K x 1
- Mifare Classes 4K x 1



Follow Us
  • Details
  • Documents
PRODUCT FEATURES
  1. Power supply: 3.3V or 5V (VUSB)
  2. Compatible with ISO14443A, ISO14443B, and ISO15693 protocols
  3. Crypto-M encryption and decryption function that is compatible with Mifare Tag
  4. Passed the NFC Forum Analog pretest Report and CE & FCC Pre-Test Report
  5. Provides software, the NFCReader_TK, to make the development easier
  6. Provides three power mode to reduce the power consumption
  7. Provides a buzzer to give an indication sound after completing a read or a write command
HARDWARE & SOFTWARE OVERVIEW

NOTE
  1. Make sure the COM port in the software matches the COM port in the device manager.
  2. Connect the SWDP on development board to a e-Link32 Pro for debugging and programming.
  3. Place the NFC tag on the antenna area for sensing.
  4. When operating the product, keep metal objects away from it.
ARCHITECTURE

The BCE-45B4523-001 is composed of three ICs, main control MCU HT32F52241, USB to UART Bridge IC HT42B534-2, and 13.56MHz NFC Reader IC BC45B4523.

After receiving UART commands from the PC, the HT32F52241 controls the BC45B4523 to transmit ISO14443 and IO15693 protocol radio frequencies via SPI interface.

Users do not need to develop software with the UART solution. They only need to use general serial port software or a built-in terminal within Windows to send commands to the NFC reader.

RESOURCES
  1. IC: Holtek BC45B4523, 13.56MHz Multi-Standard NFC Reader, including datasheet, package information, tool information, etc.
  2. MCU: Holtek HT32F52241, 32-Bit Arm® Cortex®-M0+ MCU, including datasheet, package information, tool information, etc.
  3. IC: Holtek HT42B534-2, USB to UART Bridge IC, including datasheet, package information, tool information, etc.
  4. Application Note : AN0573EN, BC45B4523 NFC Reader Development Board Application Note, including sample program.
