The BLDC Motor Driver Evaluation Kit is useful tool for BLDC control board development. It supports Hall Sensors or Sensorless Field Oriented Control (FOC), suitable for electric scooters, kitchen ventilators, ceiling fans, dust-free room Fan Filter Units and various fans, etc. The kit consists of an evaluation board ( FOC-EVB
) and a power board. Depending on the input power voltage, three power boards are provided: high voltage board ( HVPB-A
), medium voltage board ( MVPB-A
) and low voltage board ( LVPB-A
). Holtek provides a powerful software development platform (BLDC Workshop). It has many functions such as real-time parameters adjustment and output waveform monitor, generating a project and source codes to allow secondary development, etc.
