BP66FW1242 32QFN
US$0.84
In stock
Product ID
BP66FW1242-32QFN
DESCRIPTION
The BP66FW1242 is a wireless charger receiver MCU that conforms to the Qi communication protocol. It includes a synchronous full-bridge rectifier function, a linear charger function, an LDO, and a communication modulation function. In addition, it provides SPI, I2 C and UART interfaces. It is suitable for small-size wireless charger receiver devices, such as TWS headset storage case.
NOTE
The product image is for showing the product appearance, the pin count shown may not match the product pin count.
Buy 10 for
US$0.71
each and save 15 %
Buy 100 for
US$0.63
each and save 25 %
Buy 500 for
US$0.55
each and save 35 %
Buy 1000 for
US$0.50
each and save 40 %
Quantity Discounts
Follow Us for More Updates!
FEATURES
Operating Voltage: 1.8V~5.5V
Oscillators
Serial Interfaces Module – SIM for SPI or I2 C communication
Fully-duplex/half-duplex Universal Asynchronous Receiver and Transmitter Interface – UART
Software controlled LCD driver with 1/3 bias, up to 16-SCOM/SSEG lines
Up to 6 external channel 12-bit resolution A/D converter with Programmable Internal Reference Voltage VR
Full-bridge synchronous rectifier circuit
Integrated 5V LDO function
Linear charger: 1000mA (Max.)
Internal R-type and C-type modulation circuits
DEVELOPMENT TOOL
Debug Adapter : e-Link
Development Environment : HT-IDE3000
RESOURCES
MCU: Holtek BP66FW1242 , Wireless Charger Receiver Flash MCU, including datasheet, package dimension, etc.
More Information
HS Code (reference)
8542.31.0000
