Gesture Recognition Module (1D) BM32S3021-1
Gesture Recognition Module (1D) BM32S3021-1
Looking for our Official Distributor in India?
Order directly from SPIN MODULES -
local shipping and INR payment available!
Follow Us for More Updates!
PRODUCT FEATURES
- Operating voltage: 3.0V to 5.5V
- Operating current: 3mA @3.3V (no object detected)
- Operating range:
- Z–axis distance: 5cm to 25cm
- X-axis distance: ±7.5cm
- Communication interface: UART, baud rate 9600bps
- Supported gestures: swipe left and swipe right
- Gesture trigger threshold: 10 to 200 (default 16) (adjustable)
- Gesture detected time: 20ms to 1.28s (adjustable)
- Includes algorithm
- Automatic learning of sensing distance
HOW TO LEARN THE SENSING DISTANCE
The BM32S3021-1’s sensing distance is 5 to 25cm, and it is configurable. Steps for learning distance:
- To change the infrared detection position, place something, such as a sheet of paper, above the infrared sensor of the BM32S3021-1.
- For example, if you want to change the distance to 10cm, place something above the infrared sensor from a height of 10cm.
- Issue the command to the BM32S3021-1 to enter the distance learning mode. The INT pin output low under distance learning mode.
- The INT pin output high once the distance learning completed.
More Information
HS Code (reference) |
8517.79.00.00-6 |
