The e-Link32 Lite is a compact and streamlined version of the e-Link32 Pro, providing full support for ICP programming and SWD debugging of all Holtek HT32 series MCUs. It is compatible with a wide range of development and programming software, including HT32-IDE, Keil MDK, IAR, Arduino IDE, and HT32 ICP Tool.
With a USB Type-C interface, the e-Link32 Lite connects directly to a PC without the need for driver installation. It is plug-and-play, making it ideal for development and testing. Its compact size and simplified hardware design make it a cost-effective and practical choice for developers.
By connecting to a PC via USB Type-C, the e-Link32 Lite allows users to perform programming using Holtek’s HT32 ICP Tool, and debugging through HT32-IDE, Keil MDK, IAR, or Arduino IDE.
Compact and driver-free, this tool offers plug-and-play convenience for development and testing phases. Its simplified hardware design makes it a cost-effective and practical choice for developers.
Product Comparison
Feature
e-Link32 Lite
e-Link32 Pro
External power supply selection VDD
3.3V/5V/No external power supply
No external power supply
External Power Supply
O
O
Offline Programming
X
SPI Flash 8M bit
Interface Functions
SWD, Virtual UART
SWD, Virtual UART
Programming Support
HT32 Flash MCU
HT32 Flash MCU
Debugging Support
HT32 Flash MCU
HT32 Flash MCU
Supported IDEs
HT32-IDE, Keil MDK-ARM, IAR EWARM, Arduino IDE
Programming Tool
HT32_ICP_Tool
Dimensions
36.7 x 15 x 6.8 mm
84 x 42 x 13 mm
Function Description
Green LED:
Solid: USB connected successfully
Off: USB not recognized
