HT32F22366 46QFN

US$3.01
In stock
Quantity
1000 pieces
Product ID
HT32F22366-46QFN
DESCRIPTION

The HT32F22366 is Arm® Cortex®-M3 based 32-bit advanced Flash Microcontroller devices. It includes a high operating speed of up to 96MHz and is suitable for a wide range of applications such as TFT-LCD displays, biological recognition, USB game peripherals, intelligent home appliances, home automation products, consumer electronics, data collection, recorders and so on.

The HT32F22366 provides up to 256 KB of embedded Flash memory for code / data storage and 128 KB of embedded SRAM memory for system operation and application program usage. Several power saving modes provide the flexibility for maximum optimization between wakeup latency and power consumption, an especially important consideration in low power applications.

NOTE
  1. The product image is for showing the product appearance, the pin count shown may not match the product pin count.

Quantity Discounts refresh image
Select Quantity Discount Unit price
1-9 - US$3.01
10-99 15% US$2.56
100-499 25% US$2.26
500+ 35% US$1.96
For more quantity discounts please contact us
Follow Us for More Updates!
FEATURES
  1. 32-bit Arm® Cortex®-M3 processor core
  2. Up to 96 MHz operating frequency
  3. 24-bit SysTick timer
  4. 64 KB on-chip Flash memory for instruction/data and option storage
  5. 16 KB on-chip SRAM
  6. Single VDD power supply : 2.0V ~ 3.6V
  7. Supports AES Encrypt / Decrypt Function
DEVELOPMENT TOOL
  1. Integrated Serial Wire Debug Port (SW-DP)
  2. Support ISP (In-System Programming), IAP (In-Application Programming), ICP (In-Circuit Programming)
  3. Debug Adapter : e-Link32 Pro
  4. Development Environment : Keil uVision, IAR EWARM
RESOURCES
  1. MCU : Holtek HT32F22366, 32-Bit Arm®Cortex®-M3 MCU, including datasheet, package dimension, etc.
More Information
HS Code (reference) 8542.31.0000
