The medium voltage DC power board MVPB_A has an input voltage of DC 10V – 60V and delivers a maximum of 20A DC current to brushless DC motor. It should be connected to the evaluation board FOC-EVB to work with the Holtek BLDC Motor Workshop development platform. The BLDC Motor Workshop delivers the convenience of development and realizes a complete solution from evaluation, development to production.
NOTE
Please contact Holtek to get the BLDC Motor Workshop development platform software.
The motor product itself has a large working current. Careless use will cause damage to the product.
It is recommended that this product be used by professionals.
FEATURES
Input voltage: DC 10V – 60V
Maximum DC bus current: 20A
Maximum motor phase current: 6.1A, can be improved to 20.0A by changing some components
R_Shunt (Phase): 0.05Ω/2512/1%
Bus voltage divider ratio: 1/16.00
Gate-driver polarity: low side active low, high side active high
PRODUCT INFORMATION
Dimension: 88 x 80 x 60(mm)
Weight: 79.4g (net weight)
DEVELOPMENT ENVIRONMENT
Development Environment
RESOURCES
MCU : Holtek HT32F65240, 32-Bit Arm® Cortex®-M0+ MCU, including datasheet, package information, tool information, etc.
